R-600A TELEMETRY RECEIVER



See R-600A operating manual on this website for complete list of specifications.

  • Frequency range: Continuous from 216.000-221.999 MHz
  • Sensitivity: -150dBm
  • Channel steps: 1kHz with ±500Hz fine tuning
  • Antenna connector: BNC female
  • RF attenuator: -20db, -40db, -70db switchable
  • Battery: 9 volt replaceable alkaline
  • Size: 6.2" x 3.5" x 1.4" without antenna - Total footprint of receiver and antenna when viewed from above is 20.25" x 11.25". When antenna elements are folded, footprint becomes 12" x 4.75".
  • Exceptional value at $499.95
ANTENNA IN OPEN POSITION
